Code Parameter Name / Range
11-62 Selection of Preventing Oscillation
0: Mode 1
1: Mode 2
2: Mode 3
When 11-62=0: Mode 1, the response to preventing oscillation is slower (not recomended).
When 11-62=1: Mode 2, the response to preventing oscillation is faster (default). It follow hardware electric
circuit signal calculate.
When 11-62=2: Mode 3, the response to preventing oscillation is faster. Is only software calculate, but it is
possible to adjust parameters 11-69~72.
Code Parameter Name / Range
11-63 Strong Magnetic Selection
0: Disable
1: Enable
When 11-63=0, it does not have strong magnetic function.
When 11-63=1, it has the strong magnetic function.
Code Parameter Name / Range
11-69 Gain of Preventing Oscillation 3
0.00~200.00 %
Adjust the response of Gain of Preventing Oscillation 3.
If occur vibration with motor in ND mode, please increase by 0.01 unit to set.
Code Parameter Name / Range
11-70 Upper Limit of Preventing Oscillation 3
0.01~100.00 %
It is required to limit the preventing oscillation 3 upper limit within the setting value.
Code Parameter Name / Range
11-71 Time Parameter of Preventing Oscillation 3
0~30000 ms
Adjust the response of oscillation 3 function. (Time parameter of adjust preventing oscillation function delay).
Code Parameter Name / Range
11-72 Gain of Preventing Oscillation for switch frequency 1
0.01~300.00 Hz
Code Parameter Name / Range
11-73 Gain of Preventing Oscillation for switch frequency 2
0.01~300.00 Hz
238 VDI100 • Instruction manual
