230V Class: 22kW, 400V Class: 37 ~ 55kW
Terminal screw size
T
M8 M8
400V Class: 75kW
Terminal
screw size
T
M10 M10
400V Class: 90kW
Terminal screw size
T
M10 M10
400V Class: 132~160kW
Terminal screw size
T
M10 M10
Note ! For wire gauges and screw torques, please refer to the table in section 3.6
VDI100 • Instruction manual 27
