gefran VDI100 Series User Manual

Class 400V models
Models
01-07 01-09 01-21 01-23 11-59 11-60
Middle Output Volt-
age 1 of Motor 1
Minimum Output
Voltage 1 of Motor 1
Middle Output Volt-
age 1 of Motor 2
Minimum Output
Voltage 1 of Motor 2
Gain of Prevent-
ing Oscillation
Upper Limit of Pre-
venting Oscillation
1007 15.8V 25.6V 15.8V 25.6V 0.05 100
1015 15.8V 25.6V 15.8V 25.6V 0.05 100
1022 15.0V 28.0V 15.0V 28.0V 0.05 100
2037 15.0V 28.0V 15.0V 28.0V 0.05 100
2055 15.0V 28.0V 15.0V 28.0V 0.05 100
3075 15.0V 28.0V 15.0V 28.0V 0.05 100
3110 15.0V 28.0V 15.0V 28.0V 0.05 10
3150
4150
15.0V 28.0V 15.0V 28.0V 0.01 10
4185 15.0V 28.0V 15.0V 28.0V 0.01 10
4220 15.0V 28.0V 15.0V 28.0V 0.01 10
5300 17.0V 30.0V 17.0V 30.0V 0.01 10
5370 17.0V 30.0V 17.0V 30.0V 0.01 10
5450 17.0V 30.0V 17.0V 30.0V 0.01 10
5550 17.0V 30.0V 17.0V 30.0V 0.01 10
6750 17.0V 30.0V 17.0V 30.0V 0.01 10
6900 17.0V 30.0V 17.0V 30.0V 0.01 10
71100 17.0V 30.0V 17.0V 30.0V 0.01 10
71320 17.0V 30.0V 17.0V 30.0V 0.01 10
71600 17.0V 30.0V 17.0V 30.0V 0.01 10
VDI100 • Instruction manual 285
