11.4. Input EMC Filters
Install an EMC lter on power supply side to eliminate noise transmitted between the power line and the invert-
er. The inverter EMC lter below meets the EN61800-3:2012 specication.
400V Class
inverter can be ordered with integrated EMC lter (Add-on lter).
VDI100-…-2T(230V Class) models are not provided with internal / external lters.
A.VDI100-…-4-FserieswithAdd-onlterEMClter
VDI100-…-4-F series inverters are equipped with an Add-on EMC lter able to guarantee the performance
levels required by EN 61800-3:2012 standard:
• sizes 1007 to 3110: category C2 with a maximum of 10 meters of shielded motor cable,
• sizes 4150 to 5450: category C3 with a maximum of 10 meters of shielded motor cable.
B. External Input EMC Filter
VDI100-…-4 series inverters equipped with external lter below, are able to guarantee the performance levels
required by EN 61800-3:2012 standard, with the same behaviour of above internal lter
.
Table11.4.1
External InputEMCFilter
Class Model
HD Overload (150%) ND Overload (120%)
Filter type Code
Dimensions
WxHxd (Weight)
Filter type Code
Dimensions
WxHxd (Weight)
400V
3ph
1007 EMI-FTF-480-7 S7GHL 190 x 40 x 70 mm; (0.6 kg) EMI-FTF-480-7 S7GHL 190 x 40 x 70 mm; (0,6 kg)
1015 EMI-FTF-480-7 S7GHL 190 x 40 x 70 mm; (0.6 kg) EMI-FTF-480-7 S7GHL 190 x 40 x 70 mm; (0,6 kg)
1022 EMI-FTF-480-7 S7GHL 190 x 40 x 70 mm; (0.6 kg) EMI-FTF-480-16 S7GHO 250 x 45 x 70 mm; (0,8 kg)
2037 EMI-FTF-480-16 S7GHO 250 x 45 x 70 mm; (0.8 kg) EMI-FTF-480-16 S7GHO 250 x 45 x 70 mm; (0,8 kg)
2055 EMI-FTF-480-16 S7GHO 250 x 45 x 70 mm; (0.8 kg) EMI-FTF-480-30 S7GHP 270 x 50 x 85 mm; (1 kg)
3075 EMI-FTF-480-16 S7GHO 250 x 45 x 70 mm; (0.8 kg) EMI-FTF-480-30 S7GHP 270 x 50 x 85 mm; (1 kg)
3110 EMI-FTF-480-30 S7GHP 270 x 50 x 85 mm; (1 kg) EMI-FTF-480-42 S7GOA 310 x 50 x 85 mm; (1.3 kg)
3150
4150
EMI-FTF-480-30 S7GHP 270 x 50 x 85 mm; (1 kg) EMI-FTF-480-55 S7GOB 250 x 85 x 90 mm: (1.9 kg)
4185 EMI-FTF-480-42 S7GOA 310 x 50 x 85 mm; (1.3 kg) EMI-FTF-480-75 S7GOC 270 x 80 x 135 mm; (2.6 kg)
4220 EMI-FTF-480-55 S7GOB 250 x 85 x 90 mm: (1.9 kg) EMI-FTF-480-75 S7GOC 270 x 80 x 135 mm; (2.6 kg)
5300 EMI-FTF-480-75 S7GOC 270 x 80 x 135 mm; (2.6 kg) EMI-FTF-480-100 S7GOD 270 x 90 x 150 mm; (3 kg)
5370 EMI-FTF-480-75 S7GOC 270 x 80 x 135 mm; (2.6 kg) EMI-FTF-480-130 S7GOE 270 x 90 x 150 mm; (3.6 kg)
5450 EMI-FTF-480-100 S7GOD 270 x 90 x 150 mm; (3 kg) EMI-FTF-480-180 S7GOF 400 x 120 x 170 mm; (6.2 kg)
5550 EMI-FTF-480-130 S7GOE 270 x 90 x 150 mm; (3.6 kg) EMI-FTF-480-180 S7GOF 400 x 120 x 170 mm; (6.2 kg)
6750 EMI-FTF-480-180 S7GOF 400 x 120 x 170 mm; (6.2 kg) EMI 480-250 S7DGG 300 x 260 x 135 mm; (13 kg)
6900 EMI-FTF-480-180 S7GOF 400 x 120 x 170 mm; (6.2 kg) EMI 480-250 S7DGG 300 x 260 x 135 mm; (13 kg)
71100 EMI 480-250 S7DGG 300 x 260 x 135 mm; (13 kg) EMI 480-400 S7DGI 300 x 260 x 135 mm; (13.4 kg)
71320 EMI 480-250 S7DGG 300 x 260 x 135 mm; (13 kg) EMI 480-400 S7DGI 300 x 260 x 135 mm; (13.4 kg)
71600 EMI 480-400 S7DGI 300 x 260 x 135 mm; (13.4 kg) EMI 480-600 S7DGL 300 x 260 x 135 mm; (13.6 kg)
VDI100 • Instruction manual 343
