gefran VDI100 Series - Page 44

Size 5
Inverter Model
Dimensions in mm (inch)
Net Weight
kg (lbs)
W H D W1 H1 H2 t d
VDI100-5300 286.5 (11.28) 679 (26.73) 252 (9.92) 220 (8.66) 505 (19.88) 525 (20.67) 3.3 (0.13) M8 32.5 (71.65)
VDI100-5370-KXX-4-F 286.5 (11.28) 679 (26.73) 252 (9.92) 220 (8.66) 505 (19.88) 525 (20.67 3.3 (0.13) M8 32.5 (71.65)
VDI100-5450-KXX-4-F 286.5 (11.28) 679 (26.73) 252 (9.92) 220 (8.66) 505 (19.88) 525 (20.67 3.3 (0.13) M8 32.5 (71.65)
44 VDI100 • Instruction manual
