parameters for higher performance operation.
Perform auto-tuning before operation to enhance the performance of PMSLV mode. Refer to parameter 22-21
for the descriptions of PM motor tuning function.
Select the appropriate motor rating and braking resistor based on your motor and applications. Please install
the braking module in the models of
230V Class 22 kW / 400V Class 37 kW or the above.
00-00=6: SLV2 Vector Control
Verify the inverter rating matches the motor rating. Perform rotational auto-tune to measure and store motor
parameters for higher performance operation.
Refer to parameter group 17 for the descriptions of motor parameter tuning function.
Select the required V/f curve (01-00) based on your motor and applications.
Note ! Parameter 00-00 is excluded from initialization.
Code Parameter Name / Range
00-01 Motor’s rotation direction
0: Forward
1: Reverse
Use the FWD/REV key to change motor direction when Run Command Selection (00-02 = 0) is set to keypad
control.
Code Parameter Name / Range
00-02 Run command selection
0: Keypad control
1: External terminal control
2: Communication control
3: PLC
00-02=0: Keypad Control
Use the keypad to start and stop the inverter and set direction with the forward / reverse key). Refer to section
4-1 for details on the keypad.
00-02=1: External terminal control
External terminals are used to start and stop the inverter and select motor direction.
Code Parameter Name / Range
00-03 Alternative RUN Command Selection
0: Keypad control
1: External terminal control
2: Communication control
3: PLC
00-03=0: Keypad Control
Use the keypad to start and stop the inverter and set direction with the forward / reverse key). Refer to section
4-1 for details on the keypad.
00-03=1: External terminal control
External terminals are used to start and stop the inverter and select motor direction.
*Itisrequiredtobewithmulti-functiondigitalinput(12:mainandalternativerunswitchfunction).
The inverter can be operated in either 2-wire or 3-wire mode.
■ 2-wire operation
For 2-wire operation set 03-00 (S1 terminal selection) to 0 and 03-01 (S2 terminal selection) to 1.
Terminal S1 Terminal S2 Operation
Open Open Stop Inverter / FWD Active
Closed Open Run Forward
Open Closed Run Reverse
96 VDI100 • Instruction manual
