Operation
22
1
A
AA
A
Turn the side tray fine adjusting
dial as shown in the illustrations.
❖
❖❖
❖ Shifting the image to the right
❖
❖❖
❖ Shifting the image to the left
Note
❒ The image position can be shift-
ed up to about 10 mm, 0.4" each
way. Each division on the scale
is 2 mm, 0.08".
B
BB
B
Adjust the paper delivery side
plates to the print paper position.
C
CC
C
Press the {
{{
{Proof}
}}
} key to check the
image position.
TSLH02IE
TSLH02JE
To Next Page
