FIGURE 7–3. HS-300 WATER TREATMENT SYSTEM
Hot Water In
(½" NPT)
Cold Water In
(½" NPT)
Permeate Water Out
to Boiler (½" NPT)
Concentrate (Brine) Water Out
to Drain (½" NPT)
21"
21"
29"
Approximate Dimensions
A07027-V
