Getinge 600 Series User Manual

600 Series Steam Sterilizers
INS 61301607027 Rev A US 5–19
FIGURE 5–15. UPS BACK PANEL
UNPACKING Check the contents against the bill of material provided in the UPS
package.
MOUNTING When selecting a location for the UPS, observe the manufacturer’s
recommendations for operating temperature and relative humidity.
Observe the following restrictions:
• Locate the UPS within 10 feet (3 meters) of Power Box Assembly 1A.
• Do not mount the UPS on the sterilizer frame.
115 Vac Model
230 Vac Model
Connect to
Power Box 1A
Connect to
Mains Disconnect
Connect to
Mains Disconnect
Connect to
Transformer Box 9A
Input
Receptacle
Output
Receptacle
A07027-AS
