Packaging
3–2 INS 61301607027 Rev A US
UNCRATING
CAUTION
DAMAGE TO EQUIPMENT: Do not lift or position the sterilizer using the
cross members of the sterilizer frame. Doing so could misalign the door
assembly.
UNPACKING THE STERILIZER To unpack the sterilizer:
1. Move the sterilizer as close to the installation site as possible.
2. Refer to Figure 3–1 on page 3–3. Remove any packaging and shipping
material or tape.
3. Set aside the large carton containing the interior equipment.
NOTE
If a loading car and transfer carriage was purchased, the sterilizer carton will
contain a track for the loading car. The loading car and transfer carriage will
be shipped in a separate carton.
4. Set aside the small carton.
5. Set aside the kick panel.
To Next Page
