600 Series Steam Sterilizers
INS 61301607027 Rev A US 4–21
STEAM BOILER (OPTION) Two models of steam boilers are used with the 600 Series sterilizer:
• GTS-30A on 26 in. length units.
• CAS-45A on 39 in. and 51 in. length units.
If the sterilizer has an integral steam boiler, refer to “Steam Boiler” on
page 5–2 for installation details.
NOTE
The hot water supply is to meet the water quality specification on the
roughing-in drawing. A water treatment system may need to be installed in
order to meet the feedwater requirement for the boiler. See “Steam Boiler
Feedwater Quality” on page 7–5 for more information.
FIGURE 4–20. STEAM BOILER MODELS
WS-0414
CAS-45A STEAM BOILER
(vertical boiler tank)
GTS-30A STEAM BOILER
(horizontal boiler tank)
To Next Page
