INS 61301607027 Rev A US 6–1
SECTION 6 DRAWINGS
LIST OF DRAWINGS
For technical data, utility requirements, pertinent notes, and seismic
anchorage information, refer to the drawings listed in Table 6–1.
NOTE
“SP” DRAWINGS SUPERCEDE “HS” DRAWINGS: Some special orders
have a roughing-in drawing specific to the sterilizer being installed. These
drawings are indicated by an “SP” prefix and are included in the manuals
package. If a sterilizer has an “SP” drawing, install the unit according to the
requirements listed on the “SP” drawing.
INSTALLATION DRAWINGS
Figure 6-1 is the roughing-in drawing for the 600 Series Steam Sterilizer.
The content of each sheet is listed in Table 6–1.
Figure 6-2 is the seismic anchorage calculation for the 600 Series Steam
Sterilizer. Calculations for slab on grade and upper floor installations are
provided.
TABLE 6–1. INSTALLATION DRAWINGS
Title Drawing No. Page No.
600 Series Roughing-In Drawing, Steam Sterilizer, 26 in. Single Door HS-4125 Rev. C 6–2
600 Series Roughing-In Drawing, Steam Sterilizer, 26 in. Single Door w/Boiler 6–3
600 Series Roughing-In Drawing, Steam Sterilizer, 39 in. & 51 in. Single Door 6–4
600 Series Roughing-In Drawing, Steam Sterilizer, 39 in. & 51 in. Double Door 6–5
600 Series Roughing-In Drawing, Tables Document 6–6
600 Series Roughing-In Drawing, Notes Page 6–7
600 Series Roughing-In Drawing, Hold-Down Bracket Locations 6–8
600 Series Roughing-In Drawing, Seismic Anchor Information 6–9
600 Series Seismic Anchorage Calculations, Slab on Grade 700601 Rev. A 6–10
600 Series Seismic Anchorage Calculations, Upper Floor 6–12
