INS 61301607027 Rev A US 3–1
SECTION 3 PACKAGING
BEFORE YOU BEGIN
The Getinge 600 Series Sterilizers are shipped fully assembled. Only
qualified Getinge service representatives or personnel trained by Getinge
should install the sterilizer.
WARNING
POSSIBILITY OF INJURY: The sterilizer is top-heavy and could tip when
you remove it from the shipping base.
Use caution when moving the unit to ensure there is no accidental tipping
causing damage or bodily injury.
SHIPPING WEIGHT
Refer to the following chart for the weight of the crated sterilizers:
LIFTING EQUIPMENT
A pallet jack is required to remove the sterilizer from its shipping skid. Once
the skid is removed, the sterilizer can be rolled on its casters to the room
where it will be located.
CLEARANCES
The uncrated sterilizer is 39.5 inches (1003 mm) wide and 73.5 inches (1867
mm) tall. The maximum length of the sterilizer is 65.75 inches (1670 mm).
Chamber Length 26 in. 39 in. 51 in.
Single Door 1,160 lb
(526 kg)
1,365 lb
(619 kg)
1,506 lb
(683 kg)
Double Door N/A 1,508 lb
(684 kg)
1,649 lb
(748 kg)
