Installation Instructions
4–10 INS 61301607027 Rev A US
If power is not available:
a. Insert the spanner wrench into the holes in the pulley wheel.
NOTE
The spanner wrench is located in a holder on the right side of the sterilizer
frame.
b. Rotate the pulley wheel counterclockwise (CCW) until the door is
low enough to place a level inside the chamber.
FIGURE 4–11. MANUALLY OPENING THE STERILIZER DOOR
A07026-D
Door Movement
Turn Pulley CCW
