600 Series Steam Sterilizers
INS 61301607027 Rev A US 5–3
FIGURE 5–1. STEAM BOILER PLUMBING CONNECTIONS
HW
SV3
Hot Water
Pressure Relief Valve Vent
A07027-P1
See Roughing-In Drawing HS4125
for Utilities Requirements
Pressure Relief
Valve
Water
Strainer
SV3
HW
HW
SV3
Pressure Relief
Valve
Water
Strainer
Blow-Down Separator
(provided by customer)
Drain
Steam
GTS-30A STEAM BOILER
(26" length units)
CAS-45A STEAM BOILER
(39" and 51" length units)
Discharge Piping
½" ID minimum
(supplied by customer)
Manual Drain
Valve
