Setting
Following Indications are visible on the softstarter:
Power ON: Green LED for "Power On" indicates when the power is on for the softstarter.
Full Voltage: Yellow LED for "Full Voltage" indicates full voltage from the softstarter.
Following settings can be done on the softstarter.
Start time Potentiometer for setting of the ”Start Time”. 1-10 sec.
Initial voltage Potentiometer for setting of the ”Initial Voltage”.
Stop time Potentiometer for setting of the ”Stop Time”. 1-20 sec.
Set the following parameters on the softstarter:
Start time (3)
Initial voltage (4) Stop time (5)
A •
B
C • •
D
E
