DOSING
Replacing a hose in the dosing pump
This must only be done by authorized personnel.
Before starting work, make sure that the machine is disconnected from the
electric power supply.
• Remove the cover (1) by unscrewing the screw (2).
• Remove the hoses at the connections (3).
• Take out the entire unit including hose (4) (a complete spare parts kit).
• Install the new unit.
• Refit the cover.
• Validate the flow measurement.
Page 136 of 166
