Menus (2.1)
49,1 C
WASH1 TEMP SP
P1 HC SHORT 00:12:24
01 STANDBY 00:02:22
A34 I/O FAULT
00:03:00
WASH1 TIME
128,1 C
DRYER TEMP
CANCEL
DETAILS
PLOTGRAPH
BAR GRAPH
SYSTEM MENU
ABOUT
317
000
17.2 C
17.6 C
0.000 BAR
22.6 C
0.06 mBAR
21.3 C
PRINT LAST CYCLE
SELECT PACS
7
2
8
9
1
3
4
5
6
1. CANCEL
2. A34 I/O FAULT
3. ABOUT
4. SYSTEM MENU
5. SELECT PACS
6. PRINT LAST CYCLE
7. BAR GRAPH
8. PLOTGRAPH
9. DETAILS
Menus of popup list boxes. A scroll list is displayed if there are more selections available than
what is visible. The previous screen can still be seen behind the list.
CANCEL opens the Main Process Screen
DETAILS make screen (1.1) into the Main Process Screen.
PLOT GRAPH makes screen (1.2) into the Main Process Screen.
BAR GRAPH makes screen (1.3) into the Main Process Screen.
PRINT LAST CYCLE is only available during set-up
SELECT PACS is only displayed if the system has more than one PACS.
SYSTEM MENU requires a password to modify settings in PACS.
DEVICE INFO opens the device info screen.
