Getinge 9128 - Dose Monitor Calibration - Measured Volume

Dose monitor calibration - measured volume (2.1.8.2.3.2)
49,1 C
WASH1 TEMP SP
P1 HC SHORT 00:12:24
01 STANDBY 00:02:22
A34 I/O FAULT
00:03:00
WASH1 TIME
128,1 C
DRYER TEMP
CANCEL SET MAN
001812
DOSE MONITOR CALIBRATION
DET PUMP 1
DESIRED VOLUME:
MEASURED VOLUME:
ml
DOSE MONITOR TYPE UNIT FACTOR
0.154PC
0.0
0.0
3
2
4
1
1. FACTOR
2. MAN
3. SET
4. MEASURED VOLUME
Press MAN for manual calibration and enter factor. Press SET to confirm the desired volume and select
the MEASURED VOLUME field. The dose pump will then start. Use the MAN button to select the
FACTOR field.
