Drying
The machine is fitted by default with a drying system, which includes a fan, heating element, filter, heat
exchanger and air duct, temperature sensor and a pressure differential sensor.
1
2
3 4 5 6
001790
1. Sensor for pressure differential
2. Temperature sensor
3. Air duct
4. Filter
5. Heating element
6. Fan
