Temperature sensors
Adjust analog input with oil bath
1. Connect a PC with CS1000 installed.
2. Remove the temperature sensors from the machine and place them in a calibrated oil bath.
Set the temperature for the oil bath to 30°C.
3. Start CS1000 and select “Settings” > “Calibration” > “Automatic calibration”.
4. Select the sensor for "Chamber temperature" or "Drying temperature" or "Drainage
temperature" or "Booster temperature" or "Chamber independent temperature" and click on
"Calibrate".
See section Automatic calibration (2.1.6.2.2), Page 48
5. Wait until the temperature of the oil bath has stabilized at 30°C.
6. Enter the value 30 in the “Set Low” field and press “Set Low”.
7. Change the temperature of the bath to 90°C.
8. Wait until the temperature of the bath has stabilized at 90°C.
9. Enter the value 90 in the “Set High” field and click “Set High”.
10. Check that the value shows 90.
11. Click on "Close".
12. Turn off CS1000.
13. Fit the temperature sensors to the machine.
Pressure differential transmitter for drying unit (0-10 mbar)
Adjusting analog input
See section Automatic calibration (2.1.6.2.2), Page 48
