Getinge 9128 - Plotgraph

Plotgraph (1.2)
49,1 C
WASH1 TEMP SP
P1 HC SHORT 00:12:24
01 STANDBY 00:02:22
A34 I/O FAULT
00:03:00
WASH1 TIME
128,1 C
DRYER TEMP
SET UP
SELECT
CYCLE
PARA-
METERS
DISCHARGE PRESS
WASH1 TEMP SP
BAR
C
000714
1
32
8
7
9
10
6
5
4
11
12
1. WASH1 TEMP SP.
2. WASH1 TIME
3. DRYER TEMP
4. PARAMETERS
5. SELECT CYCLE
6. SETUP
7. A34 I/O FAULT
8. GRAPH
9. WASH1 TEMP SP
10. DISCHARGE PRESS
11. STANDBY
12. HC SHORT
Page 32 of 166
