Getinge 9128 - TRANSMITTER ADJUSTMENT AND CALIBRATION; Analog Input Transmitter Adjustments

Adjusting analog input
Transmitter for Conductivity control (optional) (0-500 ?S/cm or 0-5 mS/cm)
Set the output signal from the Conductivity transmitter
CAL REL
E
REL 1
REL 1
REL 2
REL 2
ALARM
MEAS
ATC
7
6
9
8
10
11
1
12
2
4
5
3
001796
1. Status indicator
2. Calibration button
3. Relay button for manual operation
4. Enter button, confirm
5. "+", "-", buttons for changing value
6. Comment
7. Measured value
8. Secondary measured value
9. Alarm indication
10. Relay indicator Manual mode
11. Relay indicator, toggle mode
12. Man/Auto button
