Dosing system
In standard form, the machine has two dosing systems. The dosing amount can be set individually for
each program.
The machine cannot be started if detergent level is to low in one of the detergent holders.
If the detergent bottle is empty, no ready-to-start signal is given. If, with the machine in this mode, the
start button is pressed, the display shows ”DET X LOW LEVEL” (X= 1,2).
You can also install a third or a fourth dosing system.
The machine is equipped with flow monitoring, which is linked to the monitoring system. If the flow of
detergent is too low, this is indicated via an alarm on the display.
1. Flowmeter for dosing
2. Dosing pumps
3. Level sensor, detergent
4. Container for detergent/rinsing agent
Page 13 of 166
