Bar graph (2.1.3)
When BAR GRAPH is selected, screen (1.3) becomes the process screen, while you go up one level in
the menu tree and end up in the process screen.
49,1 C
WASH1 TEMP SP
P1 HC SHORT 00:12:24
01 STANDBY 00:02:22
A34 I/O FAULT
00:03:00
WASH1 TIME
128,1 C
DRYER TEMP
SET UP
PARA-
METERS
CHAMBER TEMP
DISCHARGE PRESS
38,1 °C 0.000 BAR
00:19
TIME REMAINING
000715
SELECT
CYCLE
1
32
9
10
8
7
6
11
12
4
5
1. WASH1 TEMP SP
2. WASH1 TIME
3. DRYER TEMP
4. DISCHARGE PRESS
5. TIME REMAINING
6. PARAMETERS
7. SELECT CYCLE
8. SETUP
9. A34 I/O FAULT
10. CHAMBER TEMP
11. STANDBY
12. HC SHORT
