24
Air lock (SLF)
Air-lock management could be realized by means an easy electrical cable connection between
two shutters with TS 981. The required module with cable should be connected into SLF plug-in. This module
would be delivered complete within a manual.
i
When cable connection is finalized select
7.1
Automatic OPEN - Transmission
To realise Air-lock operation a push button is not required. An automatic open impulse about timer
adjustment could be selected in menu item 7.2, thereafter the present closed shutter opens when acting
shutter has closed.
Status reporting function
With the status reporting function, it is possible to display and further process the status or the fault
indications on an external device. To enable as many different applications as possible, the interface is
equipped with an RJ45 socket on the door control (SMF). This socket allows various solutions such as
connecting relay boards or bus gateways in a module housing. Note the documentation for the specific
solution.
Use menu item 7.5 to activate the status reporting module.
Software update with MMC/SD memory card
TS 981 has a slot for an MMC/SD memory card. The software can be updated or stored externally with the
memory card.
Loss of all configurations!
Before loading new software, back up the current software version of the door control.
