GFA TS981 - P 2.6 - Radio and Pull Switch Functions

33
P 2.6 - Radio and pull switch functions
 First, connect a pull / radio switch to terminal X7 or X17.
Use this menu item to determine how the door responds to a command from the radio or pull switch. Various
types of impulses can be assigned. When the pull switch / radio receiver is activated once, the following door
commands are executed depending on the door position or door movement.
Type of impulse 1: command order without STOP
Door position
Door movement after activation
Door in final limit position CLOSE
Door moves to final limit position OPEN
(with activated key
switch in intermediate open)
Door in OPEN movement
No effect
Door in final limit position OPEN
Door moves to final limit position CLOSE
Door in intermediate open
Door moves to final limit position CLOSE
Door in CLOSE movement
Door reverses and moves to
final limit position OPEN
(with activated key switch in intermediate open)
Type of impulse 2: command order with STOP
Door position
Door movement after activation
Door in final limit position CLOSE
Door moves to final limit position OPEN
(with
activated key switch in intermediate open)
Door in OPEN movement
Door stops
Door in final limit position OPEN
Door moves to final limit position CLOSE
Door in intermediate open
Door moves to final limit position CLOSE
Door between two limit positions
Door moves in the direction opposite to the last door movement
Door in CLOSE movement
Door stops
Type of impulse 3: OPEN-operation
When actuated, the door moves to the final limit position OPEN.
2.6
Pull switch or radio receiver function on X7/X17

.1
X7 / X17 = type of impulse 1
.2
X7 = type of impulse 1
X17 = type of impulse 2
.3
X7 = type of impulse 2
X17 = type of impulse 1
.4
X7 / X17 = type of impulse 2
.5
X7 / X17 = type of impulse 3
