GFA TS981 - P 1.1; 1.2 - Coarse Correction of Final Limit Position; P 1.3 - 1.5 - Fine Correction of Final Limit Positions

28
P 1.1 / 1.2 - Coarse correction of final limit position
Use these menu items to modify the final limit positions of the door that have been already set.
1.1
Coarse correction of final limit position OPEN (DES)
1.2
Coarse correction of final limit position CLOSE (DES)

Move to the desired door position using the
OPEN
or
CLOSE button
.

Save the door position by pressing the
STOP
button once.
WARNI
NG
Danger due to unattended door movement!
The safety devices are deactivated while adjusting.

Block the door for pedestrians and vehicles
.
P 1.3 – 1.5 - Fine correction of final limit positions
Use this menu item to modify the final limit positions of the door that have been already set. No door
movement takes place during fine correction. Proceed step by step.
1.3
Fine correction of final limit position OPEN (DES)
1.4
Fine correction of final limit position CLOSE (DES)
1.5
Fine correction of the safety edge‘s pre-limit (DES)
9
Correction in direction of final limit position CLOSE
_.9
Correction in direction of final limit position OPEN
i
NOTE
Use menu item
P 2.1
to activate or deactivate the safety edge
in the
pre
-
limit area.
