GFA TS981 - P 6.4 - Clearing Time; P 6.7 - Red Light Properties in Final Limit Position CLOSE; P 7.1 - Interlock Function

40
P 6.4 - Clearing time
The clearing time offers the possibility of blocking the door area for passage. The clearing time may be
necessary for large door areas (e.g., ramp in front of the door). This allows vehicles to leave the door area
before a new vehicle enters the area. The time starts when the green phase has expired or after the pre-
warning time that has been set. During this time, the red lights remain on.
6.4
Clearing time
.0
–
9.0
0 to 90 seconds.
P 6.7 - Red light properties in final limit position CLOSE
With the traffic light function activated, you can choose - depending on the requirements - whether the red
lights are on when the door is closed.
6.7
Red light properties in final limit position CLOSE
►
.0
Off
.1
Red lights inside are on
.2
Red lights outside are on
.3
Red lights inside and outside are on
P 7.1 - Interlock function
An interlock can be operated with 2 identical door controls that are connected electrically.
For the electrical connection, connect two junction boxes to the SLF socket using a plug. The junction boxes
can be purchased from GfA as a set with the associated documentation.
After wiring, activate menu item 7.1 for both door controls.
7.1
Interlock function
►
.0
Off
.1
On
