GFA TS981 - Product Overview and Installation; Technical Data

6
4 Product overview
Technical data
Designation
Expression
Dimensions (B x H x T)
190 x 300 x 115
Weight
2,5 kg
Operating frequency
50 Hz / 60 Hz
Supply voltage
1 N~
220
-
230 V, PE
3 N~ 220-400 V, PE
3~
220
-
400 V, PE
Output power for drive unit, maximum
3 kW
Temperature range
Operation
Storing
-
10 °C
-
+50 °C
0 °C
-
+50 °C
Air humidity, non
-
condensing
max. 93 %
Internal electronic protection
1000
mA
Power consumption door control
34
W
Protection class
Housing
IP65
with
CEE
connection kit
See the IP protection class of the connection kit
Protection per phase, on
-
site
10 A
External mains supply
24 V DC
External mains supply:
X1.8 / X1.9
Protection via F1 micro-fuse
1 N~230 V
1,6 A time-lag
Relay contacts
2
potential
-
free changeover
Loading of relay contacts,
ohmic
230 V AC, 1 A
24 V DC, 0,4 A
inductive
Control inputs
24 V DC, typ. 10 mA
Compatible GfA
-
limit switch
Mechanical limit switch
(NES)
Digital limit switch
(DES)
