P 2.3 - Automatic closing
With this menu item, you can select a time between 1 and 240 seconds after which the door closes
automatically. You can connect a switch for activating and deactivating this function to terminals X11.1 and
X11.2. The programmed time remains stored.
2.3
Automatic closing
►
.0
Deactivated
.1
–
2.40
. 1
= 1 second up to
9.9
= 99 seconds
For more than 99 seconds, the display will flash twice to show 3-digit numbers in full:
1.- and 0.0 = 100 seconds up to 1.- and 9.9 = 199 seconds
2.-
and
0.0
= 200
seconds up to
2.-
a
nd
40
= 240
seconds
You can interrupt automatic closing manually:
 Press the STOP button when the door is in final limit position OPEN. The door remains open.
 Press the OPEN button to reactivate automatic closing timer.
i
NOTE
With menu item
2.4
you can set whether activation of a photocell interrupts automatic closing.
P 2.4 - Reaction of automatic closing to photocell / light curtain
Use this menu item to stop automatic closing when the photocell is activated. This requires a photocell and activation of
menu item 2.3 . In operating mode ( 0.1 ) hold-to-run, this menu item has no effect.
2.4
Reaction of automatic closing to photocell / light curtain
►
.0
Deactivated
.
1
Stopping of automatic closing
2.3

The door closes 3 seconds after the interruption of the photocell
/ light curtain
has ended.
.
2
People and vessel recognition
 If the interruption of the photocell lasts less than 1.5 seconds (e.g. a person passes the door), the
door closes after the time specified in 2.3.
 If the interruption of the photocell lasts longer than 1.5 seconds (e.g. a vehicle passes the door),
the door closes after 3 seconds.
i
NOTE
If the light beam is interrupted, fault indication
F 2.1.
appears.
