P 1.6 - Door positions for intermediate open
Use this menu item to set the door position for intermediate open. Intermediate open is a door position
between final limit positions OPEN and CLOSE. This requires the connection of an external switch to the two
terminals of connector X8. Use this switch to activate and deactivate the movement to intermediate open.
This function is only available in combination with an ELEKTROMATEN having a digital limit switch.
Use menu item 2.9 to specify the command devices for moving to the position.
1.6
Setting the door positions for intermediate open

Move to the desired door position using the OPEN or CLOSE button.

Save the door position by pressing the STOP button once.
WARNING
Danger due to uncontrolled movements
During the setting, the safety devices on the door are without function.

Lock the door for pedestrians and vehicles.
P 1.7 / 1.8 - Switching position of relays X20/X21
With this menu item you can set the door position in which relays X20 and X21 switch. To use this function,
you must set menu item P 2.7/P 2.8 and connect a device to X20 and/or X21.
You only have to teach-in this switching position if you want to use the options .1 / .2 or 1. 1 of menu item 2.7 or
2.8. This menu item is only available in combination with an ELEKTROMATEN with a digital limit switch.
WARNI
NG
Danger due to unattended door movement!
The safety devices are deactivated while adjusting.

Block the door for pedestrians and vehicles
.
1.7
Setting the switching position of relay X20
1.8
Setting the switching position of relay X21

Move to the desired door position using the OPEN or CLOSE button.

Save the door position by pressing the STOP button once.
