Omnia Configurator - Creating a New Configuration Configuring Omnia PCB
MDE-5369G FlexPay™ IV (with Omnia V04.07) Programming and Service Manual · March 2021 Page 5-15
The following table provides details to select an appropriate Internal CRIND IP address for the
associated fueling position:
Note: After changing general settings while Idle loop is playing, an Omnia reboot is needed to
restore Applause Multimedia System functionalities. For more information, refer to
“Reboot” section on page 5-29.
The following table provides details to select appropriate external CRIND IP address for the
associated fueling position:
3 Once the configuration is complete, click Save and go back to the Home page.
Internal IP Scheme FlexPay IV
Fueling
Position Side
CRIND IP
Address
Default
Gateway
1/2
A 172.20.100.1 172.20.100.254
B 172.20.100.3 172.20.100.254
3/4
A 172.20.100.1 172.20.100.254
B 172.20.100.3 172.20.100.254
Card
Reader
N/A 172.16.100.2 172.16.100.1
Etc. Etc Etc. Etc.
Note: The table shows IP addresses that FlexPay IV
automatically assigns as internal IP address based
on the detected Side (A/B).
External IP Scheme FlexPay IV
Fueling
Position Side
Omnia External
IP Address
Backroom Router
IP Address Subnet Mask Primary DNS
1/2
A 10.5.55.71 10.5.55.1 255.255.255.0 10.5.55.1
B 10.5.55.72 10.5.55.1 255.255.255.0 10.5.55.1
3/4
A 10.5.55.73 10.5.55.1 255.255.255.0 10.5.55.1
B 10.5.55.74 10.5.55.1 255.255.255.0 10.5.55.1
5/6
A 10.5.55.75 10.5.55.1 255.255.255.0 10.5.55.1
B 10.5.55.76 10.5.55.1 255.255.255.0 10.5.55.1
7/8
A 10.5.55.77 10.5.55.1 255.255.255.0 10.5.55.1
B 10.5.55.78 10.5.55.1 255.255.255.0 10.5.55.1
9/10
A 10.5.55.79 10.5.55.1 255.255.255.0 10.5.55.1
B 10.5.55.80 10.5.55.1 255.255.255.0 10.5.55.1
11/12
A 10.5.55.81 10.5.55.1 255.255.255.0 10.5.55.1
B 10.5.55.82 10.5.55.1 255.255.255.0 10.5.55.1
. Etc Etc. Etc. Etc. Etc.
Notes: 1) Primary DNS value is provided by the customer or is considered to be 10.5.55.1 (if the site
uses Gilbarco-provided RV042 Router).
2) The table shows addresses that are subject to change with the site networking scheme.
Values provided in the table are for EXAMPLE ONLY.
