Parts List
EOF 10-10/20
8-03. EOF10-10 Front Header & Control Panel (Left-Side)
* Not shown
Item Part Number Qty Description
1 21101 2 SOCKET, RELAY, 8 PIN, 300V, 10A
2 21102 2 RELAY, 8 PIN, 240V, 10A
3 23751 2 TERMINAL BLOCK, 6-POLE
4 20366 1 TRANSFORMER, 20VA, 115/230V, 60HZ, CL2
5 23755 2 THERMOSTAT, SAFETY, 450°F
6 20315 2 THERMOCOUPLE, J-TYPE, 13.5, UNGROUNDED (Requires #45111, FERRULE)
7 20362 2 THERMOCOUPLE, J-TYPE, 7.5, UNGROUNDED (Requires #45111, FERRULE)
8 20365 2 THERMOCOUPLE, J-TYPE, 12", GROUNDED (Requires #45111, FERRULE)
9 21190 1 SWITCH, ROCKER, D.P.S.T. 250V, 10A
10 20398 1 INDICATOR LIGHT, GREEN, 250V, 0.5W
11 21052 2 or 3 SWITCH, ROCKER, D.P.D.T. 250V, 10A
12 20399 2 INDICATOR LIGHT, AMBER, 250V, 0.5W
13 20402 2 INDICATOR LIGHT, RED, 250V, 0.5W
14 66129 1 LABEL, CONTROL PANEL, CC10, EOF10-10
15 21380 1 CONTROLLER, CC10, DUAL DISPLAY, EOF10-10
16* 38365 1 FUSE ASSEMBLY, 1A, CONTROLLER POWER TRANSFORMER
To Next Page
