4-02. Power Test
1. Follow steps shown in Section 4-01.
2. Be sure the main circuit breaker supplying the unit power is
ON. If a Disconnect Box is used, be sure it is also ON.
3. Place the Power Switch
① in the ON position. If the green
POWER light
② illuminates, proceed to Section 4-03.
If the POWER light does not come on, refer to the
Troubleshooting procedure in Section 7-01.
1
The following test will ensure the unit has power. Perform test on each unit.
EOF 10-10/20
EOF-20
EOF-10-10
1
2
Installation Checkout & Prep
