EOF 10-10/20 Installation
2-04.1. Electrical Connections Diagram
Flexible Conduit
Terminal Blocks
Service Box
Power Wires from Quick-
Disconnect Box
Service Box Cover
Power Wires from Quick-
Disconnect Box
Ground Lug
Terminal Blocks
Service Box
Service Box Cover
Flexible Conduit
5. Connect the electrical ground wire between Ground Lug and a proper earth ground.
6. Route appropriately size power supply wires to the Disconnect and continue to Fryer.
7. Connect the power wires to the appropriate Terminal Blocks inside the Service Box, see Figure 2-04.1.
8. Reinstall Service Box Cover and close the Fryer unit Door.
