38
Fryer Operation
EOF 10-10/20
5-01. Computer Controller
The following sections explain the functions, features, programming, and operational procedures for the two
different Computer Cooking Controllers used on EOF Series Fryers ... Single & Dual Display.
5-01.1 Keys and Functions
Numeric Keypad: Used for entering Fryer settings and to edit preset Menu Item
cooking parameters. The [2-4-6-8] keys are also used as [ARROW KEYS] for operating
Basket Lifts (if installed), selecting Right/Left timer, navigating through lists, moving the
cursor when making edits, etc ... [2] - [8] = UP/DOWN ... [4] - [6] = LEFT/RIGHT. The
keys will illuminate to indicate when they are active as directional control keys.
[START]: A multiple use function key used to start cook cycles, select items from lists,
save settings, and exit editing, etc.
[CLEAR]: A multiple use function key used to cancel cook cycles, exit editing without
saving, etc.
EOF10-10, DUAL DISPLAY
EOF20
