35
EOF 10-10/20
4-04. Filter Pump Test
1. Follow steps shown in Section 4-01.
2. Open right Cabinet Door (EOF-20).
3. Place the palm of your hand over the Filter Pan quick-
disconnect fitting
①.
4. Briefly place the Pump Switch
② on the Control Panel
in the PUMP position and allow it to briefly run, then
return switch to OFF. If suction is felt at the fitting, the
pump is operating correctly, proceed to Section 4.05.
If no suction is detected, or if air seems to be blowing
outward, refer to the Troubleshooting procedure in
Section 7-02.
1
The following test will ensure the Filter Pump is operating correctly.
Installation Checkout & Prep
2
EOF-20
