Overview
EOF 10-10/20
3-03. Control Panel (EOF10-10 Dual Display)
Item Description Function
1 Power Switch The Power Switch turns Fryer power ON and OFF.
2 & 10
Heat Switch
(Left & Right Vat)
Turns power to heating elements ON/OFF. Place Switch in the OFF
position when performing certain functions and when unit is
shutdown. Place in ON position when ready to heat the oil.
3
Computer Controller
(Dual Display)
Computer Cooking Controller ... set cooking temperature and cook
times ... controls and monitors fryer functions ... displays alarm
conditions and operational instructions. Stores fifty (50) editable
Menu Item preset cook settings. Separate display for each Vat.
4 & 8
High-Limit Indicator
(Left & Right Vat)
Light is illuminated to indicate shutdown of the heating elements
due to excessive heating condition. Should this light turn on during
operation, DISCONTINUE COOKING ACTIVITIES and refer to
Troubleshooting, Section 7. DO NOT ATTEMPT TO CONTINUE
COOKING UNTIL THE CAUSE OF THIS CONDITION IS DETERMINED!
5 & 9
Heat Indicator Light
(Left & Right Vat)
Light is illuminated when the Heat Switch is in the HEAT position and
the heating elements are energized. This light will cycle ON and OFF
during normal operation as the Controller maintains the set-point
temperature.
6 Power Indicator Light
Light is illuminated whenever the main Power Switch is in the ON
position.
7 Basket Lift Switch
Enables or disables both Basket Lifts. In the LIFT position, basket lift
lowers when a cook cycle starts and is raised when cook time
expires. In the OFF position, both lifts are disabled and will not
operate.
11 Controller OLED Display
Displays Fryer setting information, alarm error messages, menu item
preset settings, and various operational messages and prompts. One
display for each Vat.
12 7-Segment Display
Main display for actual timer countdown and current actual oil
temperature. Also displays various status and/or error codes. One
display for each Vat.
