89
Parts List
EOF 10-10/20
8-02. EOF-20 Control Panel & Front Header (Right-Side)
* Hidden
Item Part Number Qty Description
1 23755 1 THERMOSTAT, SAFETY, 450°F
2 20315 2 THERMOCOUPLE, J-TYPE, 13.5, UNGROUNDED (Requires #45111, FERRULE)
3 23900 1 THERMOCOUPLE, J-TYPE, 3, GROUNDED (Requires #45111, FERRULE)
4 20366 1 TRANSFORMER, 20VA, 115/230V, 60HZ, CL2
5 23751 1 TERMINAL BLOCK, 6-POLE
6 21101 1 SOCKET, RELAY, 8 PIN, 300V, 10A
7 21102 1 RELAY, 8 PIN, 240V, 10A
8 21190 1 SWITCH, ROCKER, D.P.S.T. 250V, 10A
9 21052 2 or 3 SWITCH, ROCKER, D.P.D.T. 250V, 10A
10 21379 1 CONTROLLER, CC10, DUAL TIMER
11 20399 1 INDICATOR LIGHT, AMBER, 250V, 0.5W
12 20402 1 INDICATOR LIGHT, RED, 250V, 0.5W
13 20398 1 INDICATOR LIGHT, GREEN, 250V, 0.5W
14* 23782 1 SONALERT, CONTINUOS TONE, 250V
15 38365 1 FUSE ASSEMBLY, 1A, CONTROLLER POWER TRANSFORMER
16 66234 1 LABEL, CONTROL PANEL, CC10, EOF20
ITEM #9: Only (2) required if unit is not equipped with Auto Basket Lifts. Lift Switch position will be plugged if
not used.
