333/334 HPLC PUMPS | USER’S GUIDE
Chapter 2
CHAPTER 2 | INSTALLATION
This chapter describes the minimum connections required for operation (including procedures
for preparing piston rinse lines). The pumps must be set up and installed in the order described
in this chapter to avoid damaging the system.
TRILUTION® LC Software is the recommended controller for the pumps; however, manual
control can be achieved by controlling the 334 HPLC Pump with the control panel atop the
333 HPLC Pump.
Both pumps are delivered with the main hydraulic components installed. Solvent bottles can
be placed in the removable trays atop the pumps, on the bench, or on the floor. The pumps can
be stacked to conserve bench space.
IN THIS CHAPTER
● Electrical Connections | 20
● Cabling for TRILUTION LC Control | 24
● Cabling for Control from 333 Pump | 24
● Twin Pump Systems | 25
● Positioning the Pumps | 26
● Hydraulic Connections | 28
