Appendix B
Appendix B | COLUMn HOLdeR
Installation
The column holder attaches to the left side of the pump. Three pairs of column support, fitted
with clips for different diameter columns, are provided in the kit.
Column
Support
Retaining
Knob
Knurled
Screw
Column
Support
Retaining
Stud
Hole for
RetainingStud
Figure 57
Column Holder
in THiS CHApTeR
● Installation | 63
● Part Numbers | 64
63
333/334 HPLC PUMPS | USER’S GUIDE
