Gilson 333 - Pump Head; Electrical

61333/334 HPLC PUMPS | USER’S GUIDE
RepLACeMenT pARTS
Pump Head
PART NUMBER DESCRIPTION
38013257 H3 Pump Head
pUMp HeAd pARTS
PART NUMBER DESCRIPTION
38013311 Spacer, Rear, PEEK
3801335301 Chamber Body H3
3801335302 Rinsing Body Chamber H3
38001000 Outlet Check Valve Chamber H3
3801335304 Inlet Check Valve Chamber H3
Piston Seals
PART NUMBER DESCRIPTION
38013253 Piston Seal, Black, PTFE, Ti spring, for H3 Pump Head
38013261 Piston Seal, Yellow, UHMWPE, Ti spring, for H3 Pump Heads
Piston Assembly and Bellows
PART NUMBER DESCRIPTION
38013262 Piston assembly with bellows, for H3 pump head
38013238 Bellows, fluoroelastomer, piston rinsing compartment, for H3 pump head
Check Valve Cartridge
PART NUMBER DESCRIPTION
38013254 Inlet/Outlet Check valve cartridge, for H3 pump head
Electrical
PART NUMBER DESCRIPTION
6736004007 Fuse, 6.0A
