60
REPLACEMENT PARTS | 333/334 HPLC PUMPS
RepLACeMenT pARTS
PART NUMBER DESCRIPTION
380133552 Tubing, Stainless Steel, Left Pump to Outlet Tee, 33X Pumps
380133562 Tubing, Stainless Steel, PPMM to Outlet Filter
380133542 Tubing, Stainless Steel, Right Pump to Outlet Tee, 33X Pumps
380133742
Tubing, Stainless Steel, Outlet Tee to Pressure, Purge, and Mixing Module
(PPMM)
38013357 Tubing, FEP, Inlet Tee to Right Pump Head, 33X Pumps
38013358 Tubing, FEP, Inlet Tee to Left Pump Head, 33X Pumps
380133592 Tubing, Stainless Steel, Horizontal, 334 Tee to 333 PPMM
380132582 Tubing, Stainless Steel, Vertical, 334 Tee to 333 PPMM
49090000 Tee, HOKE, P2TTT-316
38013319 Adapters, Male, 1/4-28 (TPI), Female, 10-32 (TPI), 1mm Through, 11 μL
490310236 Ferrule, 316 Stainless Steel for 3.2 mm (1/8”) Tubing
490310235 Nut, Stainless Steel, 1/4-28 (TPI) for 3.2 mm (1/8”) Tubing
38013367 Tubing, 2.1 X 3.2, 500 mm, SS
49934609 Tubing, 1 x 1.6 x 600 mm, 471 μL
38013372 OQ Plumbing line, 333/334
38013368 Tubing, 0.13 X 1.6 X 185 mm, SS, 2 μL (seal replacement)
471078702 Tubing, FEP, 0.085 ID X 0.124 OD (Waste tubing)
49041015N Ferrule, 1/8", ETFE, Natural (P-300N)
490410315 Nut, 1/4-28 ETFE (P-315)
490310478 Plug, Stainless Steel, 1/4-28 (TPI), 333/334
490410557 Plug, White, Delrin, 5/16-24 (TPI), P-557
4904101381 Nut, White, Delrin, 5/16-24 (TPI) with 1 mm Through
490410133N Ferrule, Tefzel®, 3/16", P-133N
38013251 Drain Nut, 5/16-24, 4.8mm Tubing, TFE (Rinse Plumbing)
