77333/334 HPLC PUMPS | USER’S GUIDE
FRONT PANEL CONTROL
GSIOC ID and Miscellaneous
From the Start screen press
Edit > Config > Misc to navigate to
the Miscellaneous screen.
1. Press the Up or Down arrows to
navigate to one of the following
options:
● GSIOC unit id: (0-63). This
must be done if the 333 Pump
is slaved to another pump or
if the default ID (#1) conflicts
with other equipment.
● Bit (Baud) rate: 333 Pump
(External, 1200, 2400, 4800, 9600, 19200)
● Turn o display after ‘X’ minutes: Not used.
● Screen contrast
2. Key in the value for the GSIOC Unit ID line.
3. Press ENTER to confirm.
4. Press Change on the Bit Rate line and then select External, 1200, 2400, 4800, 9600, or
19200. External is the recommended setting.
5. Press ENTER to confirm your selection.
6. Press Next to view the second Miscellaneous screen.
7. Press Change to switch the value of Turn Off Keypad Beeper (NO or YES).
8. Press Prev to return to the first Miscellaneous screen.
9. Press Units to navigate to the Select Units screen.
10. Use the Up or Down arrows to navigate to the following options:
● Flow rate: ml/min or liter/h
● Pressure: MPa, bar, or Psi
● Injection volume: µl, ml, or l
11. Press Change to alter values for the Flow Rate, Pressure, or Injection Volume line.
12. Press ENTER to confirm.
GSIOC unit id: [--]
Bit rate: [--]
Turn off display after [--] min
Screen display contrast: ---------*
(use horizontal arrows)
Miscellaneous
Next Units
Figure 73
Miscellaneous Screen
