81333/334 HPLC PUMPS | USER’S GUIDE
FRONT PANEL CONTROL
6. Press the Up or Down arrows
to navigate to an event. If no
events exists for that file, the
Edit Method File X screen will
appear to create an event.
7. Press the Select soft key to advance
to the EditMethodFileXscreen.
The following soft keys will be
appear, allowing users to precisely
define the parameters of their
method program on various
Events screens: Flow, Comp, Wait,
Output, Other, and Inj,
NAVIGATION
● Delete: Press the Delete soft key to remove an event from a file.
● Create: Press the Create soft key to create the first event in a new file or the first event of
this type in an existing file.
● Time (Flow): Press the Time (Flow) soft key to toggle between injection flow rate and
duration.
● Add: Press the Add soft key to add an event to a file.
● List: Press the List soft key to review the events currently present in a file.
● Select: Press the Select soft key to choose an event type to add to the file.
● Confirm: Press the Confirm soft key to affirm the value entered.
● Consump: Press the Consump soft key from the Edit method screen to display the solvent
consumption (per loop).
INPUTTING FLOW EVENTS
Users must define the flow parameters for each event. The software will automatically ramp the
mobile phase flow rate up or down based on the start and end values, which are updated and
sorted as the user enters new events.
1. Press the Flow soft key on the Edit Method File X screen.
2. Key in the event time (0–9999 minutes) and flow rate. Press ENTER after each selection is
keyed-in.
3. Press the Confirm soft key once the event values are set.
4. Press the Add soft key to add a new event.
5. Repeat Steps 2–4, as needed.
Entering Method Programs
Creating and editing method program files is detailed in the following sections. You are advised
to check and correct the configuration parameters before using the edit functions to create a
list of events and the related parameters (flow rates, volumes, composition, etc.)
Creating a method program file consists of two different steps: 1) assigning a file number and
2) entering a list of events that you want to occur at the times that you specify. However, it
is recommended that you list the events required by your method program, on paper, before
attempting to create the file. See Method Program Worksheet on page 84 for a sample.
Method program files (1–20) can be looped and linked to other files.
Safety program files (21–24) are created in exactly the same way as method program files.
Creating and Editing Method Program Files
From the Start Screen press Edit > File
to access the File Directory screen.
1. Use the Up, Down, Right and Left
arrow keys to select a file number.
Unassigned files will appear as ‘-
-,’ whereas pre-assigned files will
appear in brackets.
2. Press the Edit soft key to confirm
and edit the selected file and
navigate to the Edit Method
screen. Alternatively, press the
Create soft key on an unassigned
space to create a new file. The
following options will be available:
● Method File: Displays
the current file and is not
selectable.
● Number of Loops: Indicates
the number of times the
method file is run before it
completes or links to a
separate method program file.
● When finished, link file to:
Indicates the file to be run
once the current program file
is complete.
3. Key in values for the Number of Loops and When Finished, Link File To line.
4. Press ENTER to confirm your selection(s). The Link To soft key will only appear after the
When Finished, Link File To line has been selected.
5. Press the Events soft key to reach the Events List screen.
[ 1 ] -- -- -- -- -- -- --
-- -- -- -- -- -- -- --
-- -- -- -- -- -- -- --
File Directory
Create
Figure 76
File Directory Screen
Method file: [’X’]
Number of loops: [--]
When finished, link file to: [--]
Edit Method
Events Link To
Figure 77
Edit Method Screen
Select an event type
FlowComp Wait Output Other Inj
Figure 78
Edit Method File X Screen
To Next Page
