GKB 4CH/8CH VFire Server
127
Fire/Smoke/Mask setting
The general operations are as below:
n ▲▼◄► (Mouse: Left click)
Press these buttons to select the
items.
n Numeric
Press these buttons to select the
alarm input.
n COPY ( )
Press this button to copy the settings of the focus alarm input to all the
following alarm inputs. (EX. focus alarm input is 1, its settings will be copied
to those of alarm inputs 2-8 or 4.)
n ESC (Mouse: Right Click)
Press this button to escape from this screen, and return to Setup Menu display.
If the Save dialog is shown, press ENTER to exit and save, ESC (Mouse: Right
Click) to exit without saving.
Following is a brief description for each item and its specific operations:
n Delay – the fire/smoke alarm will be treated as if it’s triggered Delay time (0-15
seconds) later after being really triggered, 0 sec. for no delay.
n Duration – response duration to define at most how long (in seconds) the
Alarm Out relay and the Buzzer will keep being triggered after fire/smoke is
detected for this camera. However, the Alarm Out relay and the Buzzer will
be reset immediately once the camera returns to normal. Press +/- buttons
to adjust the value (3 seconds - 60 minutes, discrete, ‘-‘ for ‘Forever’).
n Camera to go – the camera to go to the preset position in next field after
fire/smoke is detected for this camera. “Camera to go” camera must be a
PTZ camera.
n Goto Preset – to define the preset position to go to for the “Camera to go”
Camera in last field if fire/smoke is detected for this camera. For more details
about preset locations, please refer to Chapter 7 PTZ Control.
