GKB 4CH/8CH VFire Server
98
DVR/NVRs. And the focus window is surrounded by a frame border. In addition
to the video windows, there are different icons on the lower corner and the right
corner of the screen for status display and control. (The “.L” following the
camera title stands for Live display, “.P” for Playback, and the camera title with
white background has detected motion.)
Note 1: The frame rate is limited by the bandwidth of the network and the
pre-record IPS of the camera (Section 6.2).
Note 2: The picture quality depends on the recording resolution and recording
quality of the camera (Section 6.2).
When the user leaves I.E., he/she may be asked to save changes to files, please
enter the directory name (or use default if only one profile is needed), click on OK
or Yes to save the changes. The operations and descriptions for these icons are
as below:
n In video window, right-click the mouse button to call up Camera/Playback/Print
Dialog. (Left) click on Playback or Camera number to change the window to
the corresponding camera and live/playback mode. The user may click on
the “Print” button to print the video to the printer, or “Snapshot” the video. The
user may also double click for 1-Window display.
Click on these icons to switch the video aspect ratio between 4:3 and 16:9.
Click on these icons for 1/4/9/16/25/36/49/64-Window display. For 4/9 split
windows, the user can click on the icon, and select a different display page.
Click on this icon to switch to or return from SEQ display mode.
Click on this icon to toggle between live mode and playback mode for all the video
windows.
Click on this icon to freeze/unfreeze the video images for all the video windows.
