Short link hose supplied with the EL610A module (length 16 cm).
RAP-610D link hose (length 27 cm).
For connecting the buttons between the sound module and the EL610D button module and
between EL610D button modules.
For connecting the buttons between the sound module and the EL610D button module and
between EL610D button modules.
This hose is required when the distance between modules to be connected is greater due to
their distribution in the door panels.
DESCRIPTION OF THE DOOR PANEL
26
Description of the Nexa modular door panel:
NEXA Bus link hose (length 50 cm).
For connecting the EL632 EL642 module to the N3301/AL/ Plus or EL632-R5/EL642-R5
coded module.
Short link hose supplied with the EL610A module (length 8 cm).
RAP-610A link hose (length 55 cm).
For connecting 2 EL610A button modules in different embedding boxes.
For connections between the EL655 sound module and the EL610A button module and
between the EL610Abutton modules of the same embedding box.
AUDIO AND VIDEO DOOR ENTRY SYSTEM - ACCESS CONTROL
