Programming the Tekna Plus monitors:
AUDIO AND VIDEO DOOR ENTRY SYSTEM - CODED DOOR PANEL
PROGRAMMING THE MONITORS
From sound module:
L
ocate the SW2 DIP switch situated on the top left-hand side of the back of the EL632/PLUS module
andsetnumber 2to ON. The door panel will reproducea sound to advise that thesystemhasentered
into programmingmode.
In systems with more than one door panel, the programming process shall be done on the master door
panel only.
From coded module:
Pressthe key buttonthreetimesand thenenterthe administrator pin he willt module emittones
, :
Switch off the monitor to be programmed.
Once the telephone is off, press the door release push button.
With the door release push button pressed, switch on the monitor.
To show that the system is ready for programming, the door panel will reproduce a sound
and the picture will appears on the monitor. At this moment, the door release push button
can be released. Lift the handset to establish audio communication with the door panel.
Enter the code of the monitor to be programmed, followed by the key button.
At this moment the door panel will reproduce a sound and the monitor led will
blink.
To programme the monitor as the , switch it off and on again.Master
To programme it as a , press the door release button.Slave
To programme it as a , press the button.Slave with intercom
Each apartment must only have one master unit; if there are parallel units, whether monitors or telephones, they must be
configured as slaves.
Make a call to check that the monitor has been successfully programmed. Programme the other
telephones in the same way.
Once the programming has finished, set the programming switch to OFFsound module or press the
key if the programming is from coded module. If this is not done, the door panel will emit tones to
indicate that the system is still in programming mode .(programming from sound module)
To programme the monitor from a general entrance door panel (if any), see p. 97.
M S SI
01
01
96
Important: Programming from coded module:
- With EL632/PLUS sound module V03 or later.
- With N3301/AL or NX3301 V03 or later.
(1)
2 7 1 8
Key button + key button + key button + administrator pin.
Bear in mind the number of digits in the configured code (factory setting 2718 = 4).
(1)
C
